| Frame |
Gravel Bike Disc Brake 700C Butted / Multi-shaped Advanced Reynolds 853 Steel, 2xH2O mounts, Wide Tires Fit, 68mm threaded BB Shell, Headtube UPPER 1-1/8″/LOWER 1.5″ TAPER (46×42/55×52.1mm) L: 50/53/55/58/61CM=125/145/160/180/200mm, DROPOUTS(DO) Forged VERTICAL, W/FLAT DISC MOUNT . O.L.N: (142MM THRU-AXLE Equipped) Rear rack brazeons. |
| Fork |
CARBON ( UD WEAVE ) BLADE 700C, Steerer: CARBON 1-1/8″ to 1.5″ Taper ( I.D.:23.6) CROWN: 57mm, BLADE: CARBON STRAIGHT ( 25.7×56.9mm ) W/FLAT DISC MOUNT FOR 160 ROTOR .W/45mm OFFSET W/FORGED DROPOUTS,12mm THROUGH HOLE /M12xP1.5, Customers report Fork Fits most tires up to 700x40c (29×1.6in) |
| Crankset |
SHIMANO RX810-2, GRX, FOR REAR 11-SPEED, HOLLOWTECH 2, 48-31T, 170/172.5/175mm for 50-53/ 55 /58-61CM |
| Bottom Bracket |
SHIMANO, SM-BBR60 |
| Pedals |
ALLOY POWDER COAT BLK ROAD PEDAL W/9/16″ CNC CRMO AXLE |
| Front Derailleur |
SHIMANO FD-RX810, GRX, FOR REAR 11-SPEED, DOWN-SWING, DOWN-PULL/a |
| Rear Derailleur |
SHIMANO RD-RX810, GRX, 11-SPEED, TOP NORMAL, SHADOW PLUS DESIGN |
| Shifters |
SHIMANO ST-RX810 for Hydraulic Disc 2X11, SHIMANO R8000 FD BUILT-IN ADJUSTING FUNCTION |
| Cassette/Freewheel |
SHIMANO CS-HG70011, 11-SPEED, 11-13-15-17-19-21-23-25-27-30-34T |
| Chain |
SHIMANO CN-HG701-11, FOR 11-SPEED, 112 LINKS |
| Wheelset |
C 1800 SPLINE ® Black 23 WHEELSET, 700C ALLOY BLACK ANOD. SLEEVED TUBLESS READY W/FV
SPOKE DT SWISS STRAIGHTPULL DT NEW AERO & AERO COMP, BLACK, F/R: 24/24PCS S.S. 2 CROSS W/DT ALUMINUM NIPPLES
F/HUB DT SWISS SPLINE ALLOY ROAD BLACK db HUB 24H. ( CENTER LOCK ) OL: 12x100MM, F/HUB THROUGHAXLE QR264F 12mm, ANODIZED BLACK, L:M12xP1.5×118.5mm
R/HUB DT SWISS SPLINE ALLOY ROAD BLACK db HUB 24H. ( CENTER LOCK ) W/ 3 PAWL SYSTEM , OL: 12x142MM, COMPATIBLE SRAM 11-SPD, R/HUB THROUGHAXLE QR269R 12mm, ANODIZED BLACK, L:M12xP1.75x174mm |
| Tires |
PANARACER GRAVELKING SK 700X38C 120tpi Anti-Flat casing, ZSG Natural Compound, Tubeless Compatible , FOLDABLE, BLACK |
| Brakes |
F/ SHIMANO HYDRAULIC DISC GRX, ST-RX810(L), BR-RX810(F), 160MM ROTOR, RESIN PAD, R/ SHIMANO HYDRAULIC DISC GRX, ST-RX810(R), BR-RX810(R), FOR 25MM MNT, RESIN PAD, ROTOR FOR DISC BRAKE, SM-RT70, S 160MM, W/LOCK RING |
| Handlebar |
RITCHEY ROAD WCS EVOCURVE Alloy 7050 D.B. BUTTED B/CENTER:31.8mm 400/420/440mm FOR 50-53/ 55 /58-61CM, D/R:128/83mm, BB BLK |
| Stem/ Headset |
RITCHEY WCS C-220 84/6D ALLOY 3D Forged ALU2014 / SS Bolts. EXT:(-6 °)70/80/90mm FOR 50-53/55 /58-61CM, C/S:31.8/28.6x42mm, BB BLK |
| Tape/Grip |
Motobecane Black Gel EVA Synthetic Cork |
| Saddle |
WTB SL8 127×263, Nylon Fiber Base, CroMoly Rail, Microfiber Cover, DNA Super Light Padding |
| Seat Post |
RITCHEY WCS 1B 20mm offset 6061 ALLOY BB BLK, 27.2 X 350MM |
| Seat Clamp |
Aluminum with bolt |
| Sizes |
see pull down |
| Colors |
As Shown |
