Merlin Ltd. Edition Newsboy 2022
Due to popular demand, Merlin will be offering seven (7) limited edition Newsboys 2022. Each and every Newsboy will be custom made specifically for the customer. An homage to freewheeling ‘50s, this unique bike melds the aesthetics of a classic beach cruiser with the latest cycling technology for an unforgettable ride.
Frame $5,800.00 Build Kits Available Upon Request. More info at Merlin.
Technical Specifications
Wheel Size: 26”, 27.5″, 29″,
Fork Optional: Cusomt Merlin Titanium Newsboy
Bottom Bracket: BSA 68/73 English, PF 30, T47
Rear Hub Spacing: 142 x 12m drops – 44m
Cable Routing: External or Internal
Front Derailleur: 31.8 mm or 34.9mm Clamp-On
Derailleur Pull: Bottom, Top or Forward Pull.
Brake Type: Disc
Seatpost Diameter: 27.2 mm ( 31.6m Optional )
Seat Collar: Thomson
Recommended Use: Road, Gravel, Mountain
Manufacturer Warranty: Lifetime
Innovative BY DESIGN
Designed utilizing custom, hand contoured tubes, the Newsboy has a distinctive shape of a classic cruiser with all the accoutrements of a top-flight mountain bike.
Cold Worked Titanium
The careful shaping and cold working of the tube set results in a 45% increase to the titanium’s remarkable strength, enhancing bottom bracket stiffness while delivering a smooth, comfortable ride.
Best in Class Finish
The Newsboy’s beautifully engraved head tube badge, best in class finish, and meticulous welds are a testament to Merlin’s commitment to frame quality and esthetics.
Frame Details
Size-Specific Seamless Cold Worked 3/2.5 Oversized Titanium Tubing Throughout
Hand Made Head Badge
Dual Water Bottle Mounts with the option of additional come stock
Hand Made in the USA
Optional Merlin Titanium Newsboy Fork
Sizes: Custom
Frame Weight: 3.0 lbs (Medium)
